Tool reconditioning prices
ToolRestore – Solid carbide and indexable drills
Prices are calculated based on diameter, length, and tool geometry.
All prices fully include the following operations:
Technical inspection
CNC regrinding to DIN geometry
Edge-honing
Wet-blasting (edge preparation)
Professional cleaning
PVD coating
Measurement and dimensional control
Laser marking
Individual packaging
ToolRestore – Solid Carbide Burrs
Prices are calculated based on diameter, length, and tool geometry.
All prices fully include the following operations:
Technical inspection
CNC grinding to DIN geometry
Neck relief
Wet-blasting (edge preparation)
Professional cleaning
PVD coating
Measurement and dimensional control
Laser marking
Individual packaging
Case Study: 58% Savings
Applied example:
IZAR carbide drill Ø15.8 mm, 5xD, UF AlTiN – code 8410 16867
The adjacent graph compares two usage scenarios:
-4 new carbide drills Ø15.8 mm
-1 new drill + 3 consecutive full regrinds
Result:
Significantly reduced total cost
No real performance compromises:
Our customers report that reground tools also achieve
+20–40% tool life compared to new tools
(depending on application, material, and cutting parameters)
Technological equipment and infrastructure
5-Axis CNC Tool Grinding Machine META
- Simultaneous 5-axis interpolation
- Dedicated software for regrinding over 100 DIN geometries
- Renishaw 3D probes
- Tool grinding Ø2- Ø25 mm
PVD Plated Swiss Pi311 Coating Technology
The coating is carried out in ovens with PLATIT (Switzerland) technology, using the PVD (Physical Vapor Deposition) process, in a vacuum, at temperatures of approximately 500°C.
This process deposits a hard protective layer, based on titanium compounds, which increases wear and temperature resistance.
We offer 9 main types of PVD coatings, selected according to the application and the material being processed:
AlTiN, TiAlN, nACo³, TiXCo³, DLC, nACRo, TiCN-MP, TiCN and CrN.
